Heating Capacity at Air 27℃/24℃, Water 27℃ in, 29℃ out
| 007TB1 | 010TB1 | 012TB1 | 015TB1 | 019TB1 | |
| Heating Capacity(kw) | 7.2 | 10 | 12.5 | 15 | 18.8 |
| Power input (kW) | 1.19 | 1.63 | 2.05 | 2.45 | 3.13 |
| C.O.P. | 6.05 | 6.13 | 6.10 | 6.12 | 6.01 |
Heating Capacity at Air 15℃/12℃, Water 26℃ in, 28℃ out
| 007TB1 | 010TB1 | 012TB1 | 015TB1 | 019TB1 | |
| Heating Capacity(kw) | 5.1 | 7.2 | 9.5 | 12.5 | 15.5 |
| Power input (kW) | 1.0 | 1.4 | 1.86 | 2.44 | 3.06 |
| C.O.P. | 5.1 | 5.14 | 5.11 | 5.12 | 5.06 |
Heating Capacity at Air 35℃/24℃, Water 29℃ in, 27℃ out
| 007TB1 | 010TB1 | 012TB1 | 015TB1 | 019TB1 | |
| Heating Capacity(kw) | 4.5 | 6.5 | 8.5 | 11.2 | 14 |
| Power input (kW) | 1.3 | 1.8 | 2.39 | 3.22 | 4.11 |
| EER | 3.46 | 3.62 | 3.56 | 3.48 | 3.41 |
General Specifications
| 007TB1 | 010TB1 | 012TB1 | 015TB1 | 019TB1 | |
| Voltage | 220-240V/1/50Hz | ||||
| Max Power Input (kw) | 1.8 | 2.5 | 3.0 | 3.6 | 4.7 |
| Max Current (A) | 9.1 | 12.6 | 15.2 | 18.2 | 24.5 |
| Refrigerant | R410A | ||||
| Heat Exchanger | Titanium | ||||
| Air Flow Direction | Horizontal | ||||
| Water Flow Volume(m*/h) | 3 | 4 | 5 | 6.5 | 8 |
| Automatic Defrosting | by 4 way valve | ||||
| Working Temp. Range (°C) | -15~43 | ||||
| Water Connection (mm) | 50mm | ||||
| Noise Level (dB(A)) | ≤48 | ≤51 | ≤58 | ≤72 | ≤85 |
| Net Weight (kg) | 46 | 51 | 58 | 72 | 85 |
